QZ3321BR-5L1-02 SMC Solenoid Valve H63467 H1124E for Fuji NXT/XPF SMT Placement Head Spare Parts

Product Description & Introduction

VQZ3321BR-5L1-02 is an SMC 5-port pneumatic solenoid valve primarily used for the pneumatic control system of Fuji NXT and XPF SMT placement machine heads.

This solenoid valve controls the air switching function inside the placement head, ensuring stable nozzle operation, reliable component pickup, and smooth movement of the placement head. It is a critical pneumatic control component that affects the stability of SMT equipment operation.

This valve is associated with Fuji part numbers:

Fuji Part No.: H63467
Fuji Cross Reference: H1124E

It is suitable for Fuji SMT machine maintenance, repair, and refurbishment applications. As a commonly used SMT pneumatic spare part, it helps reduce equipment downtime caused by valve aging, air leakage, or unstable pneumatic switching.

Based on the proven SMC VQZ3000 series design, this solenoid valve provides stable pneumatic control, reliable sealing performance, and long service life, making it suitable for long-term high-frequency operation in SMT production environments.

Product Specifications

Model	VQZ3321BR-5L1-02
Brand	SMC
Fuji Part No.	H63467
Fuji Cross Reference	H1124E
Valve Type	5-Port Solenoid Valve / Pneumatic Valve
Series	SMC VQZ3000 Series
Coil Voltage	DC24V
Working Medium	Clean Compressed Air
Operating Pressure	0.1-0.7 MPa
Connector Type	L-Type Electrical Connector
Application Position	Placement Head Pneumatic Control System
Compatible Machines	Fuji NXT / Fuji XPF SMT Placement Machine

Product Features

Fuji NXT/XPF Compatibility: Designed for Fuji NXT and XPF placement head pneumatic systems, suitable for SMT equipment repair, replacement, and spare part inventory.
Stable Pneumatic Switching Performance: Based on the reliable SMC VQZ3000 series structure, it provides stable air switching performance to ensure smooth nozzle operation and placement head movement.
Suitable for High-Frequency SMT Production: With reliable sealing performance and durability, this valve is designed for continuous and repeated operation in SMT production environments.
Helps Reduce Equipment Downtime: Aging or damaged solenoid valves may cause air leakage, unstable nozzle suction, abnormal placement head movement, or pneumatic alarms. Replacing this component helps restore stable pneumatic control performance.
Quality Checked Before Shipment: Each product is inspected before shipment to ensure stable quality and basic functional reliability.

Frequently Asked Questions

Q1: Which machines is VQZ3321BR-5L1-02 compatible with?

This solenoid valve is mainly used for Fuji NXT and Fuji XPF SMT placement machine heads.

Q2: What Fuji part numbers are related to this valve?

Related Fuji references:

Fuji Part No.: H63467
Fuji Cross Reference: H1124E

Q3: What is the function of this solenoid valve?

This valve controls the pneumatic air switching inside the placement head, affecting nozzle operation, component pickup stability, and placement head performance.

Q4: When should this solenoid valve be replaced?

Common replacement situations include:

Unstable nozzle suction
Air leakage
Abnormal placement head movement
Pneumatic system alarms
Unstable machine operation

Q5: Is this valve ready for SMT machine maintenance use?

Yes. Each unit is checked before shipment and is suitable for Fuji SMT machine maintenance, replacement, and daily production line support.
